lightweight buggy

More
22 May 2021 05:43 - 22 May 2021 05:46 #235259 by X8GGY
Replied by X8GGY on topic Re:lightweight buggy
"Not much turning circle"?...



Not surprised with the size of them there tyres B) Awesome...!

Ummm, I was thinking "little" 195/80-15 (27.5" x 7.8") Extreme Trekkers on mine... so they'lll fit and turn :woohoo:

Small buggy, small budget, small tyres...


Last edit: 22 May 2021 05:46 by X8GGY.

Please Log in or Create an account to join the conversation.

More
22 May 2021 07:39 - 22 May 2021 07:43 #235260 by Baloo
Replied by Baloo on topic Re:lightweight buggy
hi Dave
         yes a bit large for an offroader but they were for a lawnmower that did a specific task,  i have a wood that ive mowed a buggy track through and as its at the bottom of the field its always wet in there and a normal mower just sinks and leaves ruts

File Attachment:


File Attachment:



i dont know off the top of my head how wide a jimny chassis is but i would guess its about 32" so if you chop 12" out of the axle then the chassis will need the same to allow the wheels to turn  then you will end up with a 24" wide chassis  which sounds spot on for a single seater.
when you starting it lol
Last edit: 22 May 2021 07:43 by Baloo.

Please Log in or Create an account to join the conversation.

More
22 May 2021 07:41 #235261 by Baloo
Replied by Baloo on topic Re:lightweight buggy
Replied by  Old Neil  on topic  Re:lightweight buggy
Just wondering it sat for a while could a rodent chewed on some wiring

Sent from my SM-A305YN using Tapatalk


Hi Old Neil,    that stands more than a chance, ive had all sorts of critters move into my vehicles, will try and get onto it over the weekend

Please Log in or Create an account to join the conversation.

More
22 May 2021 07:46 #235262 by Baloo
Replied by Baloo on topic Re:lightweight buggy
anyone know how much second hand chassis change hands for ???     i would like to make a start but not really ready to strip this one yet

Please Log in or Create an account to join the conversation.

More
22 May 2021 10:05 #235263 by X8GGY
Replied by X8GGY on topic Re:lightweight buggy

hi Dave
         yes a bit large for an offroader but they were for a lawnmower that did a specific task,  i have a wood that ive mowed a buggy track through and as its at the bottom of the field its always wet in there and a normal mower just sinks and leaves ruts

File Attachment:


File Attachment:



i dont know off the top of my head how wide a jimny chassis is but i would guess its about 32" so if you chop 12" out of the axle then the chassis will need the same to allow the wheels to turn  then you will end up with a 24" wide chassis  which sounds spot on for a single seater.
when you starting it lol

I’m planning on making the chassis for it...

I have kinda started, amassing parts, brains ticking all the time about it*, “saving” for the tyres at the moment...

* I found through the lockdown that self isolating in the garage, and a build occupying my mind during long days in the shop (watching the general public bouncing off each and forgetting their masks, etc) has kept me sane through it all... so I figured build another one!

Great looking track! B)

Our mate James Priestley breaks the odd Jimny, I’ve massaged him to see if he has a chassis ;)

Please Log in or Create an account to join the conversation.

More
22 May 2021 10:21 - 22 May 2021 10:23 #235264 by X8GGY
Replied by X8GGY on topic Re:lightweight buggy
James has a chassis :woohoo: I’ve PM’d you his number...

Dave ;)
Last edit: 22 May 2021 10:23 by X8GGY.

Please Log in or Create an account to join the conversation.

More
23 May 2021 16:10 - 23 May 2021 16:10 #235287 by Baloo
Replied by Baloo on topic Re:lightweight buggy
Hi David
       thanks for that, I've been in touch with James and he's  going to let me know what he's got,  lm also going to to look at a Jimmy pick up with no engine and box which might fit the bill if it comes cheap enough
Cheers Andy
Last edit: 23 May 2021 16:10 by Baloo.
The following user(s) said Thank You: X8GGY

Please Log in or Create an account to join the conversation.

More
17 Jun 2021 16:14 #235859 by Baloo
Replied by Baloo on topic Re:lightweight buggy
right time to get a move on here,  need to get this one running,  i have no check engine light  but it refuses to start

ive pulled off a fuel hose on top of the engine  when i turn the ign key on i expected the fuel pump to run for a few seconds to bring the pressure in the line up for the injectors,  no fuel comes out of this hose/pipe    should it ?   i cant hear the fuel pump run     can you normally ?
is there access to the fuel pump under the back seat ?  anyone ?
Attachments:

Please Log in or Create an account to join the conversation.

  • Riccy
  • Riccy's Avatar
  • Offline
  • Banned
  • Banned
    Registered
  • J999 MNY Bashing around Carlisle
More
17 Jun 2021 16:51 - 17 Jun 2021 16:52 #235865 by Riccy
Replied by Riccy on topic Re:lightweight buggy
Hi Baloo.

In the picture you have the return line disconnected. Its not letting fuel out because the solenoid before it will be shut. Try putting a vaccum to the little hoop of pipe before the solenoid, otherwise the feed line is down near the starter motor im afraid. The filter is in the tank also.

To access the pump you need to drop the tank out or cut a hole in the floor.

Hope that helps

J999 MNY, ULYSSES M18 VVT with ITB's Dyno tested at 130hp

Pickup/tipper, R7me gearbox & 6.4 Rocklobster, 31" Toyo MT, 2x ARB air locker 3.9 diffs in braced axles, 6" total lift, Floating rear conversion, Raptor painted, CB, Recaro's, Caged, etc, etc...

www.youtube.com/user/riclemus
Last edit: 17 Jun 2021 16:52 by Riccy.

Please Log in or Create an account to join the conversation.

  • Lambert
  • Lambert's Avatar
  • Away
  • Moderator
  • Moderator
    Registered
  • The quickest Jimny in Harrogate...(that I own)
More
17 Jun 2021 16:52 #235866 by Lambert
Replied by Lambert on topic Re:lightweight buggy
Usually you can hear the pump prime. Unfortunately there's not an inspection plate you have to lower the tank.

Temeraire (2018 quasar grey automatic)
One of the last 200ish of the gen3s, probably.

Please Log in or Create an account to join the conversation.

More
17 Jun 2021 17:09 #235869 by Baloo
Replied by Baloo on topic Re:lightweight buggy
Hi
     the feed pipe down by the starter looked harder to get at lol,   i will try that pipe next then   if no joy there then its time to cut a hole under the back seat i guess

thank you

Please Log in or Create an account to join the conversation.

More
17 Jun 2021 17:10 #235870 by Baloo
Replied by Baloo on topic Re:lightweight buggy

Usually you can hear the pump prime. Unfortunately there's not an inspection plate you have to lower the tank.

i cant hear a thing but then im deaf lol,    will investigate further


Please Log in or Create an account to join the conversation.
