transfer bearing kit
- Jimny - aus
- Topic Author
- New Member
-
Public
17 Mar 2013 22:00 #66132
by Jimny - aus
transfer bearing kit was created by Jimny - aus
have diagnosed my transfer problem to be the input bearing....... now to source a bearing kit.. does anyone know if there is an aftermarket kit available or shall i proceed getting F#$cked and get a genuine kit... :pinch:
Please Log in or Create an account to join the conversation.
17 Mar 2013 22:51 #66142
by facade
If it suddenly breaks, go back to the last thing that you did before it broke and start looking there
Replied by facade on topic transfer bearing kit
Depends on how much time you have.
I've never seen the electric transfer, but on the lever type, the input shaft runs in two ball races, you split the casing, remove circlips and they come out, I doubt if much has changed.
Once they are out any good bearing supplier should be able to match them for you or you can read the bearing numbers and just order them.
I've never seen the electric transfer, but on the lever type, the input shaft runs in two ball races, you split the casing, remove circlips and they come out, I doubt if much has changed.
Once they are out any good bearing supplier should be able to match them for you or you can read the bearing numbers and just order them.
If it suddenly breaks, go back to the last thing that you did before it broke and start looking there
Please Log in or Create an account to join the conversation.
- gus2000
- New Member
-
Public
18 Mar 2013 00:22 #66147
by gus2000
Replied by gus2000 on topic transfer bearing kit
Hello, in the lever type transfer case, the three oil seal are identicals. (29972-80050)
if you do not use original parts, with the helical ribbed seals be careful with the direction of rotation of the oil seals.
Front and rear shafts rotating in different direction, relative to the oil seal
Expel the oil out if wrong rotating
Gustavo
if you do not use original parts, with the helical ribbed seals be careful with the direction of rotation of the oil seals.
Front and rear shafts rotating in different direction, relative to the oil seal
Expel the oil out if wrong rotating
Gustavo
